BLP35M805Z

Overview

The BLP35M805 is a 5 W LDMOS power transistor designed for high-power continuous wave applications across the HF to 3500 MHz frequency range. It operates with a drain-source voltage of up to 65 V and features an integrated electrostatic discharge protection circuit. The device utilizes a thermally enhanced HVSON16 package (SOT1371-1) with dimensions of 4 x 6 x 0.85 mm. In class-AB operation at 2450 MHz, it delivers 5 W output power with 20 dB gain and 50% drain efficiency. At 3500 MHz, it maintains 5 W output with 9.6 dB gain and 33% efficiency under specified bias conditions.

Feature Summary

• High power gain and efficiency suitable for broadband RF amplification
• Excellent ruggedness capable of withstanding significant load mismatches
• Integrated electrostatic discharge protection for improved handling reliability
• Thermally enhanced plastic package optimized for heat dissipation

Applications

• Broadcast transmitter driver stages
• Industrial, Scientific and Medical (ISM) equipment
• Aerospace and Defense communication systems

Procurement Notes

Verify component authenticity by checking the manufacturer's official documentation against the physical marking on the SOT1371-1 package. Ensure that the ordering suffix matches the specific revision required for your design. Confirm RoHS compliance status directly from the supplier's current product declaration before finalizing procurement orders.

Selection Notes

Select this component for single-ended amplifier designs requiring robust performance in the HF to 3500 MHz spectrum. Evaluate thermal management requirements carefully, as the junction-to-case thermal resistance dictates the necessary heatsinking strategy. Ensure the application circuit supports the specified gate-source threshold voltage and biasing conditions for optimal linearity.

Part Context

This part belongs to Ampleon's portfolio of LDMOS power transistors engineered for demanding RF environments. It serves as a specialized driver stage solution where high power density and wide bandwidth are critical. The device integrates advanced packaging technologies to support efficient thermal transfer in compact board layouts.

Replacement Considerations

Consult official Ampleon documentation for verified substitute part numbers. Do not assume functional equivalence with other manufacturers' devices without comprehensive electrical characterization and impedance matching adjustments.

FAQ

What is the maximum load mismatch the BLP35M805 can withstand?

The device can withstand a load mismatch corresponding to a Voltage Standing-Wave Ratio (VSWR) of 10:1 through all phases during class-AB operation.

Is the BLP35M805 suitable for automotive applications?

No, unless explicitly stated otherwise in the data sheet, this product is not qualified or tested according to automotive standards and should not be used in automotive equipment.

What type of package does the BLP35M805 use?

It uses the HVSON16 package (SOT1371-1), which is a plastic thermal enhanced very thin small outline package with no leads and 16 terminals.
