C4ATFBW5400A3NJ

C4ATFBW5400A3NJ is listed in the Film Capacitors range at ChipApex. The manufacturer field lists KEMET. Its product description is CAP FILM 40UF 5% 400VDC RADIAL. Review the specifications below when checking this part for your BOM.

Film Capacitors specifications for C4ATFBW5400A3NJ

• Description：CAP FILM 40UF 5% 400VDC RADIAL
• Series：C4AT
• Mfr：KEMET
• Package：Bulk
• Capacitance：40 µF
• Tolerance：±5%
• Voltage Rating - AC：250V
• Voltage Rating - DC：400V
• Dielectric Material：Polypropylene (PP), Metallized
• Operating Temperature：-40°C ~ 85°C
• Mounting Type：Through Hole
• Package / Case：Radial - 4 Leads
• Size / Dimension：2.264" L x 1.378" W (57.50mm x 35.00mm)
• Height - Seated (Max)：1.969" (50.00mm)
• Termination：PC Pins
• Lead Spacing：2.067" (52.50mm)
• Applications：DC Link, DC Filtering; High Frequency, Switching
• Ratings：-
• Features：-
• ESR (Equivalent Series Resistance)：1.4 mOhms

Film Capacitors datasheet and documents for C4ATFBW5400A3NJ
