CGH27030S-AMP1

Overview

The CGH27030S-AMP1 is a test fixture designed for the MACOM CGH27030S GaN HEMT. It supports operation from 1800 MHz to 2200 MHz with an output power of 30 W. The device utilizes a 28 V rail and features a surface-mount DFN package configuration.

Feature Summary

• Provides a standardized test environment for RF transistor evaluation
• Compatible with 28 V operating rails
• Supports high-power output testing at 30 W

Applications

• RF amplifier characterization
• GaN HEMT performance validation
• Development board testing

Procurement Notes

Verify compatibility with the specific CGH27030S component model before procurement. Confirm that the test fixture meets the required frequency range of 1800 MHz to 2200 MHz for your application. Ensure the 28 V rail specification aligns with your power supply setup. Check for any specific handling requirements associated with RF test fixtures.

Selection Notes

Select this fixture specifically for evaluating the CGH27030S within the 1.8 GHz to 2.2 GHz band. It is suitable for applications requiring 30 W output power verification. Consider the physical interface requirements for integrating the fixture into your existing test bench infrastructure.

Part Context

This item belongs to the MACOM RF development tools category, specifically designed as a test fixture. It complements the CGH27030S GaN HEMT by providing a controlled environment for performance assessment. The fixture facilitates accurate measurement of key parameters such as gain and efficiency.

Replacement Considerations

No public confirmed substitute part numbers are available for this specific test fixture model.
