CTDS5022PF-333

Fixed Inductors Overview

The CTDS5022PF-333 is a surface-mount shielded power inductor from Central Technologies. It features a fixed inductance of 33 µH and supports a maximum DC current of 860 mA. The component exhibits a maximum DC resistance of 780 mΩ. Designed for general-purpose applications, it utilizes a non-standard form factor suitable for automated assembly processes.

Fixed Inductors Feature Summary

• Shielded magnetic structure to minimize electromagnetic interference
• Surface-mount design optimized for automated placement
• General-purpose power inductor construction

Fixed Inductors Applications

• DC-DC converter circuits
• Power supply filtering stages
• General electronic equipment signal conditioning

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet for precise electrical tolerances and thermal characteristics. Confirm that the component meets required environmental standards for the intended deployment environment. Ensure compatibility with standard reflow soldering profiles during integration.

Fixed Inductors Selection Notes

Select this component when a compact shielded inductor with moderate current handling is required. Evaluate the 780 mΩ resistance against system efficiency targets. Consider the physical dimensions for PCB layout constraints compared to unshielded alternatives.

Fixed Inductors Part Context

This part belongs to the CTDS5022PF series of shielded power inductors manufactured by Central Technologies. The series offers various inductance values within a consistent physical footprint, allowing for standardized mechanical design across different circuit configurations requiring magnetic shielding.

Fixed Inductors Replacement Considerations

Cross-reference with other shielded SMD inductors offering similar 33 µH inductance and comparable current ratings. Verify pinout compatibility and mechanical footprint alignment before substitution.
