DF2378BVLP35V

Description：IC MCU 16BIT 512KB FLSH 145TFLGA
Series：H8® H8S/2300
Mfr：Renesas Electronics Corporation
Package：Tray
Core Processor：H8S/2000

SKU:2ac8f03a97d3 Category: Microcontrollers Brand: Renesas Electronics Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DF2378BVLP35V is listed in the Microcontrollers range at ChipApex. The manufacturer field lists Renesas Electronics Corporation. Its product description is IC MCU 16BIT 512KB FLSH 145TFLGA. Review the specifications below when checking this part for your BOM.

Microcontrollers specifications for DF2378BVLP35V

Description：IC MCU 16BIT 512KB FLSH 145TFLGA
Series：H8® H8S/2300
Mfr：Renesas Electronics Corporation
Package：Tray
Core Processor：H8S/2000
Core Size：16-Bit
Speed：35MHz
Connectivity：I2C, IrDA, SCI, SmartCard
Peripherals：DMA, POR, PWM, WDT
Number of I/O：96
Program Memory Size：512KB (512K x 8)
Program Memory Type：FLASH
EEPROM Size：-
RAM Size：32K x 8
Voltage - Supply (Vcc/Vdd)：3V ~ 3.6V
Data Converters：A/D 16x10b; D/A 6x8b
Oscillator Type：External
Operating Temperature：-20°C ~ 75°C (TA)
Mounting Type：Surface Mount
Supplier Device Package：145-TFLGA (9x9)
Package / Case：145-TFLGA
Grade：-
Qualification：-

Microcontrollers datasheet and documents for DF2378BVLP35V

DF2378BVLP35V

Microcontrollers Overview

The DF2378BVLP35V is a 16-bit microcontroller from the Renesas H8S/2300 series, utilizing the H8S/2000 core. It features 512KB of flash memory and 32KB of RAM, operating at a maximum clock frequency of 35MHz. The device is housed in a 144-pin TFLGA package with dimensions of 9x9mm. It includes integrated peripherals such as DMA, multiple ADC and DAC channels, and various communication interfaces.

Microcontrollers Feature Summary

Integrates a 16-bit H8S/2000 core for general-purpose system control applications.
Supports direct memory access (DMA) to reduce CPU overhead during data transfers.
Includes built-in analog-to-digital and digital-to-analog converters for signal processing.
Offers multiple serial communication interfaces including SCI and I2C.

Microcontrollers Applications

General-purpose system control
Industrial automation controllers
Consumer electronics appliances

Microcontrollers Procurement Notes

Verify component authenticity through authorized Renesas distributors or sales offices. Confirm current product status as legacy support may apply. Check for RoHS compliance and moisture sensitivity levels before procurement. Ensure packaging specifications match design requirements.

Microcontrollers Selection Notes

Select this model for designs requiring 16-bit processing with moderate memory capacity. Consider the TFLGA package constraints for PCB layout. Evaluate peripheral needs against available ADC/DAC channels. Review thermal performance within the specified operating temperature range.

Microcontrollers Part Context

This component belongs to the H8S/2378 Group, which is supported primarily for existing customers. New designs are recommended to utilize the RX651 Group instead. The H8S architecture provides a balance of performance and cost for established industrial applications.

Microcontrollers Replacement Considerations

The RX651 Group is the recommended replacement for new designs due to enhanced security and connectivity features. Direct pin-compatible substitutes are not explicitly documented; migration requires architectural review.
