EET-UQ2W221EA

EET-UQ2W221EA is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is CAP ALUM 220UF 20% 450V SNAP TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for EET-UQ2W221EA

• Description：CAP ALUM 220UF 20% 450V SNAP TH
• Series：TS-UQ
• Mfr：Panasonic Electronic Components
• Package：Bulk
• Capacitance：220 µF
• Tolerance：±20%
• Voltage - Rated：450 V
• ESR (Equivalent Series Resistance)：904mOhm @ 120Hz
• Lifetime @ Temp.：2000 Hrs @ 85°C
• Operating Temperature：-25°C ~ 85°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：1.55 A @ 120 Hz
• Ripple Current @ High Frequency：2.17 A @ 10 kHz
• Lead Spacing：-
• Size / Dimension：1.378" Dia (35.00mm)
• Height - Seated (Max)：0.984" (25.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can - Snap-In

Aluminum Electrolytic Capacitors datasheet and documents for EET-UQ2W221EA
