EGXE251ELL470ML25S

EGXE251ELL470ML25S is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Chemi-Con. Its product description is CAP ALUM 47UF 20% 250V RADIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for EGXE251ELL470ML25S

• Description：CAP ALUM 47UF 20% 250V RADIAL TH
• Series：GXE
• Mfr：Chemi-Con
• Package：Bulk
• Capacitance：47 µF
• Tolerance：±20%
• Voltage - Rated：250 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：2000 Hrs @ 125°C
• Operating Temperature：-40°C ~ 125°C
• Polarization：Polar
• Ratings：AEC-Q200
• Applications：Automotive
• Ripple Current @ Low Frequency：225 mA @ 120 Hz
• Ripple Current @ High Frequency：337.5 mA @ 100 kHz
• Lead Spacing：0.295" (7.50mm)
• Size / Dimension：0.630" Dia (16.00mm)
• Height - Seated (Max)：1.063" (27.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can
• Impedance：-

Aluminum Electrolytic Capacitors datasheet and documents for EGXE251ELL470ML25S
