EP4SGX70DF29C2XG

Field Programmable Gate Array Overview

The EP4SGX70DF29C2XG is a Stratix IV GX Field Programmable Gate Array (FPGA) manufactured by Altera. It features 72,600 logic elements and 2,904 Adaptive Logic Modules (ALMs). The device includes 7,564,880 bits of embedded memory and supports 372 I/O pins. It operates with a supply voltage range of 0.87V to 0.93V and functions within a junction temperature range of 0°C to 85°C. The component is housed in a 780-ball FCBGA package.

Field Programmable Gate Array Feature Summary

• Stratix IV GX series FPGA with 72,600 logic elements
• 7,564,880 bits total embedded memory capacity
• 372 available I/O pins for interface connectivity
• Operates at 0.87V ~ 0.93V supply voltage

Field Programmable Gate Array Applications

• High-performance digital signal processing systems
• Complex logic control applications requiring significant programmable resources
• Industrial automation controllers
• Telecommunications infrastructure equipment

Field Programmable Gate Array Procurement Notes

Verify the specific suffix 'XG' against official manufacturer documentation to confirm pinout and electrical characteristics. Confirm RoHS compliance status and moisture sensitivity level (MSL 3) prior to PCB assembly planning. Ensure compatibility with Quartus Prime software versions supporting the Stratix IV family.

Field Programmable Gate Array Selection Notes

Select this model when a balance of moderate logic density (72k LEs) and high I/O count (372) is required. Compare against EP4SGX70 variants with different packages if board space constraints exist. Verify that the 780-FBGA footprint matches the design layout. Check if the 0-85°C industrial temperature range meets environmental requirements.

Field Programmable Gate Array Part Context

This part belongs to the Altera Stratix IV GX family, designed for high-speed serial communications and complex logic. It shares architectural similarities with other Stratix IV devices but offers specific resource scaling. The 'GX' designation typically indicates support for high-speed transceivers, though specific transceiver counts should be verified in the datasheet.

Field Programmable Gate Array Replacement Considerations

Direct replacements include other EP4SGX70 variants with compatible packages, such as EP4SGX70DF29C2N or EP4SGX70HF35C4G, provided pinouts and thermal specifications align. Cross-family migration to Cyclone V or Arria V requires significant redesign.
