F-132P

Overview

The Triad Magnetics F-132P is a power transformer designed for printed circuit board (PCB) mounting. It features a single primary winding rated for 115 VAC input and a secondary output of 18.0 VCT at 0.600 A, resulting in a 10.8 VA power rating. The component utilizes wire lead termination for secure electrical connections. It operates within a temperature range of 0°C to +130°C and complies with UL and cUL safety standards.

Feature Summary

• Single primary winding configuration for simplified circuit integration
• Chassis or PCB compatible design with wire lead termination
• Compliant with UL and cUL safety certifications

Applications

• Industrial control systems requiring isolated power supply
• Electronic equipment chassis mounting applications
• General purpose AC to DC power conversion stages

Procurement Notes

Verify the specific voltage and current ratings against the official datasheet before procurement. Confirm that the single primary winding matches the available line voltage. Ensure the PCB layout accommodates the wire lead spacing and physical dimensions. Check for updated regulatory compliance status prior to finalizing orders.

Selection Notes

Select this model when a compact, single-primary power transformer is required for PCB assembly. It is suitable for applications needing 18VCT isolation at moderate current levels. Consider the operating temperature range and safety approvals to ensure compatibility with the target enclosure and regional regulations.

Part Context

The F-132P belongs to the Triad Magnetics F series of industrial power transformers. This series typically offers robust construction for demanding environments. The component serves as a critical isolation stage between mains voltage and low-voltage circuitry in various electronic assemblies.

Replacement Considerations

Consult the manufacturer's cross-reference guide for verified substitutes. Ensure any replacement maintains identical electrical parameters and mounting footprint.
