FD6M033N06

FET, MOSFET Arrays Overview

The FD6M033N06 is a synchronous rectifier module manufactured by onsemi, formerly Fairchild Semiconductor. It integrates dual N-channel MOSFETs within a single package to optimize efficiency in power conversion circuits. The device is rated for a drain-source voltage of 60V and supports a continuous current of 73A. Designed specifically for synchronous rectification applications, it utilizes advanced planar stripe DMOS technology to minimize on-state resistance and enhance switching performance.

FET, MOSFET Arrays Feature Summary

• Integrates dual N-channel MOSFETs into a single synchronous rectifier module
• Optimized for high-efficiency power conversion with low on-state resistance
• Utilizes planar stripe DMOS technology for superior switching performance
• Designed to withstand high energy pulses in avalanche and commutation modes

FET, MOSFET Arrays Applications

• High-efficiency switch mode power supplies (SMPS)
• Synchronous rectification stages in DC-DC converters
• Active power factor correction (PFC) circuits
• Low voltage, high current output regulation modules

FET, MOSFET Arrays Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels due to the discontinued status. Confirm lot codes and date codes against current inventory records. Ensure storage conditions comply with moisture sensitivity level requirements prior to assembly. Request detailed test reports if available to validate electrical parameters against original datasheet specifications.

FET, MOSFET Arrays Selection Notes

Select this component for designs requiring integrated dual MOSFETs in a compact form factor. Evaluate thermal management capabilities given the 73A current rating. Compare total gate charge and reverse recovery characteristics against alternative discrete solutions. Ensure the 60V voltage rating aligns with the specific bus voltage requirements of the target application circuit.

FET, MOSFET Arrays Part Context

This part belongs to the broader family of power MOSFETs produced by Fairchild Semiconductor, now operating under onsemi. It represents the transition from discrete components to integrated modules aimed at reducing board space and improving reliability. The FD series typically targets high-current, low-voltage applications where efficiency and thermal performance are critical design constraints.

FET, MOSFET Arrays Replacement Considerations

As the FD6M033N06 is marked as obsolete, verify functional equivalents such as the NVBYST0D8N08X or similar synchronous rectifier modules from onsemi. Ensure pin compatibility and thermal footprint match the existing PCB layout before substitution.
