IAUC120N06S5N017ATMA1

$2.22

Description：MOSFET N-CH 60V 120A TDSON-8-43
Series：OptiMOS™
Mfr：Infineon Technologies
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:2f772c69b2dd Category: Single FETs, MOSFETs Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IAUC120N06S5N017ATMA1 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Infineon Technologies. Its product description is MOSFET N-CH 60V 120A TDSON-8-43. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for IAUC120N06S5N017ATMA1

Description：MOSFET N-CH 60V 120A TDSON-8-43
Series：OptiMOS™
Mfr：Infineon Technologies
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：60 V
Current - Continuous Drain (Id) @ 25°C：120A (Tj)
Drive Voltage (Max Rds On, Min Rds On)：-
Rds On (Max) @ Id, Vgs：1.7mOhm @ 60A, 10V
Vgs(th) (Max) @ Id：3.4V @ 94µA
Gate Charge (Qg) (Max) @ Vgs：95.9 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：6952 pF @ 30 V
FET Feature：-
Power Dissipation (Max)：167W (Tc)
Operating Temperature：-55°C ~ 175°C (TJ)
Grade：Automotive
Qualification：AEC-Q101
Mounting Type：Surface Mount
Supplier Device Package：PG-TDSON-8-43
Package / Case：8-PowerTDFN

Single FETs, MOSFETs datasheet and documents for IAUC120N06S5N017ATMA1

IAUC120N06S5N017ATMA1

Single FETs, MOSFETs Overview

The IAUC120N06S5N017ATMA1 is an OptiMOS™-5 N-channel enhancement mode power MOSFET designed for automotive applications. It features a PG-TDSON-8-43 package and supports a drain-source voltage of 60 V with a maximum on-state resistance of 1.7 mΩ at 10 V gate drive. The device handles a continuous drain current of 120 A and a pulsed current of 757 A, dissipating up to 167 W. It operates within a temperature range of -55 °C to +175 °C, includes 100% avalanche testing, and meets MSL1 standards.

Single FETs, MOSFETs Feature Summary

OptiMOS™-5 technology optimized for automotive environments
High thermal robustness with 175 °C operating capability
Validated avalanche energy performance

Single FETs, MOSFETs Applications

Automotive power distribution systems
High-current load switching circuits
DC-DC converter topologies

Single FETs, MOSFETs Procurement Notes

Verify the specific ordering suffix ATMA1 against official Infineon documentation to confirm reel packaging specifications. Ensure compatibility with PG-TDSON-8-43 footprint requirements during PCB layout. Confirm RoHS compliance status through the manufacturer's certificate of conformity prior to integration into production lines.

Single FETs, MOSFETs Selection Notes

Select this component when low conduction losses are critical in high-current automotive designs. The 60 V rating suits 12 V and 48 V system architectures. Evaluate the thermal resistance characteristics against the target PCB copper area to ensure junction temperatures remain within safe operational limits under continuous load conditions.

Single FETs, MOSFETs Part Context

This transistor belongs to the OptiMOS™-5 family, representing advanced trench gate technology from Infineon Technologies. It is engineered specifically for the automotive sector, providing enhanced ruggedness compared to standard industrial counterparts. The part integrates robust gate oxide protection and optimized cell geometry for superior efficiency.

Single FETs, MOSFETs Replacement Considerations

Direct replacements require matching the PG-TDSON-8-43 package and 60 V / 1.7 mΩ electrical profile. Verify that alternative candidates also possess AEC-Q101 certification and equivalent avalanche ratings to maintain system reliability in automotive contexts.
