IPL1-125-01-L-D-K

Headers, Male Pins Overview

The IPL1-125-01-L-D-K is a Mini Mate® header connector with 50 positions in a dual row configuration. It features a 0.100" (2.54mm) pitch and vertical through-hole termination. The contacts are gold-plated phosphor bronze pins, while the housing is made of natural LCP rated UL94 V-0. Rated for 275VAC and 389VDC, it utilizes slide-lock fastening and four-wall shielding.

Headers, Male Pins Feature Summary

• Individually shrouded square pin contacts for precise alignment
• Four-wall shielded housing for electromagnetic interference protection
• Slide-lock fastening mechanism for secure board attachment
• Gold contact plating ensures reliable signal transmission

Headers, Male Pins Applications

• High-density power distribution systems
• Industrial control panel interconnections
• Telecommunications equipment backplanes
• Automotive electronic module connections

Headers, Male Pins Procurement Notes

Verify the specific part number suffix against official Samtec documentation to confirm exact pin count, plating thickness, and insulation material properties. Ensure that the selected variant matches the required current rating and voltage specifications for the intended application environment before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a robust, shielded header is required for high-current applications. The Mini Mate® series offers elevated stack height options and optional locking clips. Confirm compatibility with mating socket strips such as the IPS1 series to ensure proper mechanical engagement and electrical performance within the system design.

Headers, Male Pins Part Context

This connector belongs to the Mini Mate® IPL1 series, designed for discrete wire and board-to-board applications. It provides a reliable connection solution with high durability. The series supports various termination styles and contact configurations to meet diverse industrial and commercial connectivity requirements.
