M22-2030505

$0.37

Description：CONN HEADER R/A 5POS 2MM
Series：M22
Mfr：Harwin Inc.
Package：Bulk

SKU:2895211c276b Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M22-2030505 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER R/A 5POS 2MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M22-2030505

Description：CONN HEADER R/A 5POS 2MM
Series：M22
Mfr：Harwin Inc.
Package：Bulk
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：5
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.138" (3.50mm)
Contact Length - Post：0.118" (3.00mm)
Overall Contact Length：-
Insulation Height：0.079" (2.00mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：-
Contact Finish - Post：-
Contact Material：Phosphor Bronze
Insulation Material：Polyamide (PA6T), Nylon 6T
Features：-
Operating Temperature：-55°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：1A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for M22-2030505

M22-2030505

Headers, Male Pins Overview

The M22-2030505 is a male pin header connector from the Harwin M22 series, designed for through-hole mounting. It features a single row with five positions and a 2.00mm pitch. The connector utilizes right-angle horizontal orientation for board-to-board applications. Contact surfaces are gold-plated copper alloy pins with a mating length of 3.5mm. Insulation is provided by black polyamide (PA6T) rated UL94 V-0. Electrical ratings include 500V operation within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

Right-angle horizontal design facilitates compact board-to-board interconnections.
Gold-plated contacts ensure reliable signal transmission and corrosion resistance.
UL94 V-0 rated polyamide insulation provides thermal stability and flame retardancy.

Headers, Male Pins Applications

Board-to-board interconnects in consumer electronics
Industrial control system module connections
Automotive electronic sub-system linking

Headers, Male Pins Procurement Notes

Verify component authenticity against official Harwin documentation due to discontinued status. Confirm that replacement sources provide valid traceability records. Ensure storage conditions maintain contact integrity prior to assembly. Cross-reference datasheet specifications with supplier certificates to guarantee compliance with RoHS3 standards before final procurement approval.

Headers, Male Pins Selection Notes

Select this specific model when a five-position, right-angle male header is required. Verify that the 2.00mm pitch matches the target PCB footprint. Ensure the 3.5mm mating pin height aligns with the counterpart socket depth. Confirm that through-hole termination suits the manufacturing process and that the 500V rating meets circuit requirements.

Headers, Male Pins Part Context

This component belongs to the M22 series, characterized by high-density interconnect capabilities. The M22-2030505 variant specifically addresses space-constrained designs requiring robust mechanical locking via push-pull mechanisms. It serves as a critical interface element in multi-layer PCB architectures where vertical clearance is limited but electrical reliability remains paramount.
