M50-3600842

Headers, Male Pins Overview

The M50-3600842 is a surface mount header from the Harwin Archer M50 series, featuring a 1.27 mm (0.05 in) pitch and 16 positions arranged in a single row. Designed for board-to-board or wire-to-board applications, it utilizes male pin contacts with gold plating on a brass substrate. The connector supports a current rating of 1 A and operates within a temperature range of -40°C to +105°C. It employs a solder termination type and includes an insulating housing made of thermoplastic material rated UL 94 V-0.

Headers, Male Pins Feature Summary

• Surface mount design optimized for automated pick-and-place assembly processes
• Gold-plated male pin contacts ensure reliable electrical connectivity
• Thermoplastic housing provides UL 94 V-0 flame retardancy

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• High-density electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Harwin documentation to confirm exact mating height and packaging configuration. Ensure compatibility with standard SMT reflow profiles and check for RoHS compliance status through certified datasheets before finalizing procurement specifications.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row surface mount header is required for 1.27 mm pitch systems. Consider the 16-position count and straight orientation for space-constrained designs. Validate that the 1 A current rating and thermal limits meet the target application's operational requirements.

Headers, Male Pins Part Context

This part belongs to the Archer M50 family, which consolidates various mating heights for 1.27 mm pitch connectors. The series is engineered for high-density PCB layouts, offering robust mechanical stability and consistent electrical performance across diverse industrial and consumer electronics environments.

Headers, Male Pins Replacement Considerations

Consult official Harwin cross-reference guides for verified substitutes. Generic equivalents may not match the precise mating height or contact geometry required for reliable integration.
