M50-4902345

Headers, Male Pins Overview

The Harwin M50-4902345 is a double-row IDC cable connector from the Archer M50 series. It features a 1.27 mm pitch and contains 26 positions per row, totaling 52 contacts. The connector is designed for right-angle installation and utilizes a female socket configuration. Constructed with gold-plated phosphor bronze contacts and a PBT housing, it supports a current rating of 1A and a voltage rating of 300V AC. The operating temperature range spans from -40°C to +105°C.

Headers, Male Pins Feature Summary

• Features a secure latch mechanism to ensure quick mating and reliable connection stability during operation.
• Utilizes gold-plated phosphor bronze contacts to provide low contact resistance and enhanced corrosion resistance.
• Designed with a shrouded housing structure to prevent misalignment and protect contacts during insertion.

Headers, Male Pins Applications

• High-density interconnects in compact electronic assemblies
• Data transmission lines requiring reliable signal integrity
• Industrial control systems with space constraints

Headers, Male Pins Procurement Notes

Verify the specific part number suffix against official Harwin documentation to confirm exact pin count and orientation. Ensure compatibility with mating headers regarding pitch and shroud design. Confirm that the selected variant meets the required environmental ratings for the intended application environment.

Headers, Male Pins Selection Notes

Select this component when a high-density, right-angle IDC connection is required within tight spatial limits. The 1.27 mm pitch allows for significant I/O density on PCBs. Consider the gold plating for environments where oxidation resistance is critical for long-term signal reliability.

Headers, Male Pins Part Context

This component belongs to the Harwin Archer M50 series, which is engineered for high-reliability applications. The series offers various configurations including straight and right-angle options, catering to diverse board layout requirements while maintaining consistent electrical performance standards across the product line.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult Harwin's official cross-reference tools or datasheets for verified alternatives if discontinuation occurs.

Headers, Male Pins FAQ

What is the contact material used in this connector?

The contacts are made of phosphor bronze with a gold plating finish.

Does this connector include a locking mechanism?

Yes, it features a latch mechanism to ensure secure mating and connection stability.
