MPCV1060L1R5

$1.97

Description：FIXED IND 1.5UH 22A 2.75MOHM SMD
Series：MPCV
Mfr：KEMET
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:6098970d56f4 Category: Fixed Inductors Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MPCV1060L1R5 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists KEMET. Its product description is FIXED IND 1.5UH 22A 2.75MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for MPCV1060L1R5

Description：FIXED IND 1.5UH 22A 2.75MOHM SMD
Series：MPCV
Mfr：KEMET
Package：Tape & Reel (TR),Cut Tape (CT)
Type：-
Material - Core：Metal Composite
Inductance：1.5 µH
Tolerance：±20%
Current Rating (Amps)：22 A
Current - Saturation (Isat)：27A
Shielding：Shielded
DC Resistance (DCR)：2.75mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：AEC-Q200
Operating Temperature：-55°C ~ 155°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.472" L x 0.394" W (12.00mm x 10.00mm)
Height - Seated (Max)：0.236" (6.00mm)
Features：-

Fixed Inductors datasheet and documents for MPCV1060L1R5

MPCV1060L1R5

Fixed Inductors Overview

The KEMET MPCV1060L1R5 is a shielded metal composite power inductor designed for surface-mount applications. It features an inductance of 1.5 µH with a saturation current of 27 A and an RMS current rating of 22 A. The component exhibits a maximum DC resistance of 2.75 mΩ. It operates within a temperature range of -40°C to +125°C and complies with RoHS standards.

Fixed Inductors Feature Summary

Utilizes metal composite technology for high current handling capabilities
Shielded construction minimizes electromagnetic interference
Optimized for compact DC-to-DC switching power supply designs

Fixed Inductors Applications

Automotive DC-to-DC switching power supplies
Point-of-load voltage regulation modules
High-density power conversion circuits

Fixed Inductors Procurement Notes

Verify the specific manufacturer part number against official KEMET documentation to ensure authenticity. Confirm that the component meets the required automotive or industrial specifications for your application. Check for any recent design changes or obsolescence notices directly from the manufacturer before finalizing procurement plans.

Fixed Inductors Selection Notes

Select this component when high current density and low core losses are critical. The metal composite material offers superior performance compared to traditional ferrite cores at high frequencies. Ensure the thermal management strategy supports the 125°C operating limit and that the footprint accommodates the nonstandard case dimensions.

Fixed Inductors Part Context

This inductor belongs to the MPCV series, which utilizes proprietary metal composite materials. This series is engineered to provide high saturation currents and low AC losses. It serves as a key passive component in modern power electronics where space constraints and efficiency requirements are stringent.
