PDS1-S5-S24-S

PDS1-S5-S24-S is listed in the DC DC Converters range at ChipApex. The manufacturer field lists CUI Inc.. Its product description is DC DC CONVERTER 24V 1W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for PDS1-S5-S24-S

• Description：DC DC CONVERTER 24V 1W
• Series：PDS1-S (1W)
• Mfr：CUI Inc.
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：5.5V
• Voltage - Output 1：24V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：42mA
• Power (Watts)：1 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：SCP
• Operating Temperature：-40°C ~ 105°C (With Derating)
• Efficiency：81%
• Mounting Type：Through Hole
• Package / Case：4-SIP Module
• Size / Dimension：0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CB Scheme, EN, IEC, UL
• Standard Number：55024; 55032 Class A; 60950-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for PDS1-S5-S24-S
