PZC15SABN

Headers, Male Pins Overview

The PZC15SABN is a vertical male header connector manufactured by Sullins Connector Solutions. It features a 15-position single-row configuration with a 0.100-inch (2.54mm) pitch. Designed for through-hole mounting, the connector utilizes square pins with gold plating on the mating surface and tin plating on the tail. The housing is constructed from black polybutylene terephthalate (PBT) rated UL94 V-0. It supports a maximum current of 3A and operates within a temperature range of -65°C to 125°C.

Headers, Male Pins Feature Summary

• Vertical male pin header design for board-to-board or cable connections
• Through-hole termination with push-pull locking style
• Gold-plated square contact surfaces for reliable signal transmission
• UL94 V-0 rated black PBT insulation for flame resistance

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics assembly
• Telecommunications equipment modules
• General-purpose circuit board expansion

Headers, Male Pins Procurement Notes

Verify component authenticity against official Sullins Connector Solutions documentation. Confirm that the specific suffix matches required plating and material specifications. Check for obsolescence status as distributors may list discontinued items. Ensure compatibility with mating female connectors regarding pitch and row count. Request updated RoHS compliance certificates if required for final assembly regulations.

Headers, Male Pins Selection Notes

Select this connector when a vertical male header with 15 positions and 2.54mm spacing is required. Ensure the application environment stays within the specified -65°C to 125°C operating range. Verify that the PCB layout accommodates the through-hole pad dimensions and overall height constraints. Confirm that the mating interface accepts square pins with the specified contact length.

Headers, Male Pins Part Context

This component belongs to the PBC/PZC series of breakaway headers from Sullins Connector Solutions. These connectors are designed for high-density applications requiring reliable electrical performance. The series offers various positioning options and plating choices to suit different environmental and mechanical requirements.

Headers, Male Pins Replacement Considerations

Compatible substitutes include PBC15SAFN and PBC15SADN from the same manufacturer family. Verify that alternative parts maintain identical 15-position counts, 2.54mm pitch, and vertical orientation. Cross-reference pin dimensions and plating thicknesses to ensure mechanical and electrical compatibility.
