SX5B10.000F2020F30

Crystals Overview

The SX5B10.000F2020F30 is a surface-mount crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a fundamental frequency of 10 MHz with a standard tolerance of ±10 ppm. The component utilizes a 4-SMD, no-lead package configuration designed for automated assembly processes. Electrical characteristics include a load capacitance of 20 pF and an equivalent series resistance (ESR) of 80 Ohms. This specific model variant is identified by the suffix F30, indicating its packaging and handling specifications within the SCTF product line.

Crystals Feature Summary

• Provides stable 10 MHz timing signals for digital circuit synchronization
• Designed for direct surface mounting without lead structures
• Optimized for high-volume automated pick-and-place manufacturing

Crystals Applications

• General-purpose clock generation in consumer electronics
• Timing reference sources for microcontroller systems
• Synchronization circuits in communication modules

Crystals Procurement Notes

Verify the exact package dimensions against your PCB footprint library before ordering. Confirm that the 20 pF load capacitance matches your circuit design requirements to ensure frequency accuracy. Check the ESR value of 80 Ohms against your oscillator circuit constraints. Ensure the supplier provides official datasheets for the F30 suffix specification.

Crystals Selection Notes

Select this component when a 10 MHz fundamental frequency is required in a compact surface-mount form factor. The 20 pF load capacitance suits standard CMOS logic interfaces. Consider the 80 Ohm ESR for driver strength compatibility. Evaluate the SMD no-lead package for space-constrained designs requiring reflow soldering capabilities.

Crystals Part Context

This part belongs to the SCTF crystal oscillator family, which offers various frequencies and packages. The SX5 series typically denotes standard performance crystals suitable for general applications. The 10 MHz frequency is a common industry standard for system clocks. The manufacturer specializes in providing precise timing solutions for electronic assemblies.

Crystals FAQ

What is the load capacitance for this crystal?

The specified load capacitance is 20 pF.

Does this component have leads?

No, it uses a 4-SMD, no-lead package design.
