TAV2-501+

$1.87

Description：RF MOSFET E-PHEMT 4.5V MC1631-1
Series：-

SKU:bc005ccf1703 Category: RF FETs, MOSFETs Brand: Mini-Circuits

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF MOSFET E-PHEMT 4.5V MC1631-1
Series：-
Mfr：Mini-Circuits
Package：Tape & Reel (TR),Cut Tape (CT)
Technology：E-pHEMT
Frequency：400MHz ~ 3.9GHz
Gain：23.5dB
Voltage - Test：4.5 V
Current Rating (Amps)：-
Noise Figure：1.3dB
Current - Test：280 mA
Power - Output：-
Voltage - Rated：7 V
Grade：-
Qualification：-
Mounting Type：Surface Mount
Package / Case：8-TFDFN Exposed Pad
Supplier Device Package：MC1631-1
Configuration：-

Download product information

TAV2-501+

Overview

The TAV2-501+ is a low-noise, medium-power E-PHEMT MMIC amplifier operating from 0.9 GHz to 4.5 GHz. It features a typical noise figure of 0.6 dB at 0.9 GHz and high OIP3 of +42.9 dBm at 2 GHz under 4.5V bias. The device offers footprint compatibility with the ATF-501P8.

Feature Summary

Utilizes E-PHEMT technology for low noise and medium power performance
Provides footprint compatibility with the ATF-501P8 component

Applications

Low noise amplification in RF front ends
Medium power signal boosting in communication systems
Direct replacement integration for ATF-501P8 designs

Procurement Notes

Verify the specific datasheet revision (e.g., REV. A) matches your design requirements. Confirm that the E-PHEMT technology and pinout are compatible with your existing PCB layout intended for the ATF-501P8. Ensure your biasing circuit supports the specified 4.5V operation for optimal noise and linearity performance.

Selection Notes

Select this component when a direct physical replacement for the ATF-501P8 is required without redesigning the board. It is suitable for applications needing low noise figures around 0.6 dB and high linearity (+42.9 dBm OIP3) within the 0.9 to 4.5 GHz range. Consider thermal management if operating near maximum current limits.

Part Context

This part belongs to Mini-Circuits' portfolio of surface-mount MMIC amplifiers designed for chip and wire or SMT integration. It represents a specialized solution for engineers needing to maintain form-factor continuity while upgrading or sourcing alternative active components for RF signal chains.

Replacement Considerations

Officially documented as a footprint-compatible substitute for the ATF-501P8. Verify electrical parameter differences against the original design specifications before implementation.
