TSM-106-02-S-DV-LC

$2.42

Description：CONN HEADER SMD 12POS 2.54MM
Series：TSM
Mfr：Samtec Inc.
Package：Tube,Tube

SKU:04b590c0f70b Category: Headers, Male Pins Brand: Samtec Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TSM-106-02-S-DV-LC is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is CONN HEADER SMD 12POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for TSM-106-02-S-DV-LC

Description：CONN HEADER SMD 12POS 2.54MM
Series：TSM
Mfr：Samtec Inc.
Package：Tube,Tube
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：12
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.320" (8.13mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：30.0µin (0.76µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Liquid Crystal Polymer (LCP)
Features：Board Lock
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：-
Voltage Rating：-

Headers, Male Pins datasheet and documents for TSM-106-02-S-DV-LC

TSM-106-02-S-DV-LC

Headers, Male Pins Overview

The TSM-106-02-S-DV-LC is a board connector featuring six contacts arranged in a single row. It utilizes male, straight surface mount terminals with a rectangular contact pattern and square pin-sketch style. The component has a black insulator and includes split board lock mounting options. Contact finishes consist of gold over nickel for mating surfaces and matte tin with a nickel barrier for termination.

Headers, Male Pins Feature Summary

Designed specifically for surface mount applications with mixed technology pin options
Features .025 inch square post terminal strips for enhanced mechanical stability
Supports high mating cycles and extended life performance standards

Headers, Male Pins Applications

High-speed data transmission requiring signal integrity
Automotive A-Series product integration
Severe environment testing qualified installations

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm the exact configuration, as variations exist for tape-and-reel packaging or lead time modifications. Ensure compatibility with the intended mating socket height and verify RoHS compliance status against current manufacturing revisions before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when surface mount assembly is required for rigid board-to-board connections. The square post design offers superior durability compared to standard pins. Consider the split board lock feature if additional mechanical retention during soldering is necessary for the specific PCB layout constraints.

Headers, Male Pins Part Context

This part belongs to the TSM series of .100 inch pitch surface mount terminal strips. It is an Extended Life Product designed to meet rigorous reliability standards. The series supports various row configurations and pin orientations to accommodate diverse interconnect requirements in compact electronic assemblies.
