TSW-134-26-G-D

Headers, Male Pins Overview

Samtec TSW-134-26-G-D is a classic PCB header strip featuring 68 positions in a dual-row configuration. It utilizes a 2.54 mm (0.1 in) pitch with straight through-hole solder pin termination. The connector employs phosphor bronze contacts with gold plating and a polybutylene terephthalate (PBT) housing. Rated for up to 6.3 A current and 550 VAC voltage, it operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Dual-row male pin header design for board-to-board or cable connections
• Gold-plated phosphor bronze contacts ensure reliable signal transmission
• Straight orientation with through-hole solder termination for secure mounting

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board assemblies
• General electronic circuit integration

Headers, Male Pins Procurement Notes

Verify the specific part number TSW-134-26-G-D against official Samtec documentation to confirm the 68-position count and dual-row layout. Ensure compatibility with standard 2.54 mm mating connectors. Check RoHS compliance status and UL 94 V-0 flammability ratings prior to procurement to meet project safety standards.

Headers, Male Pins Selection Notes

Select this component when a high-density 68-pin connection is required on a single row pair. The 2.54 mm pitch suits standard PCB layouts. Consider the 5.84 mm mating length for adequate engagement depth. Verify that the 6.3 A current rating meets the application's electrical load requirements without derating.

Headers, Male Pins Part Context

This part belongs to the Samtec TSW series of classic PCB header strips. These headers are designed for general-purpose connectivity, offering a balance of performance and cost. The TSW series provides various position counts and row configurations to accommodate diverse board spacing and density needs.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Samtec TSW series headers with identical 2.54 mm pitch and 68 positions, such as TSW-134-xx-G-D variants. Ensure replacement parts maintain the same dual-row structure and through-hole termination style.
