VLF3012AT-100MR49

$0.57

Description：FIXED IND 10UH 490MA 410MOHM SMD
Series：VLF
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:0cf87825b7fa Category: Fixed Inductors Brand: TDK Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

VLF3012AT-100MR49 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists TDK Corporation. Its product description is FIXED IND 10UH 490MA 410MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for VLF3012AT-100MR49

Description：FIXED IND 10UH 490MA 410MOHM SMD
Series：VLF
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Drum Core, Wirewound
Material - Core：Ferrite
Inductance：10 µH
Tolerance：±20%
Current Rating (Amps)：490 mA
Current - Saturation (Isat)：490mA
Shielding：Shielded
DC Resistance (DCR)：410mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 105°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.110" L x 0.102" W (2.80mm x 2.60mm)
Height - Seated (Max)：0.047" (1.20mm)
Features：-

Fixed Inductors datasheet and documents for VLF3012AT-100MR49

VLF3012AT-100MR49

Fixed Inductors Overview

The VLF3012AT-100MR49 is a shielded surface-mount power inductor from TDK's VLF series. It features a ferrite drum core and wirewound construction, designed for high-density mounting. The component has an inductance of 10 µH with a ±20% tolerance. It supports a maximum DC current of 490 mA and exhibits a maximum DC resistance of 410 mOhms. Operating within a temperature range of -40°C to +105°C, it measures 2.8 mm in length, 2.6 mm in width, and 1.2 mm in height.

Fixed Inductors Feature Summary

Shielded magnetic structure enables high-density circuit board installation.
Low-profile design optimizes space constraints in portable devices.

Fixed Inductors Applications

DC-DC converter chokes
Portable charger circuits
Mobile device power management

Fixed Inductors Procurement Notes

Verify the specific suffix 'R49' against official TDK documentation to confirm the precise electrical ratings, as variations exist within the VLF family. Confirm RoHS compliance status through the manufacturer's environmental declarations prior to integration into lead-free manufacturing processes.

Fixed Inductors Selection Notes

Select this component when a compact footprint is required alongside moderate current handling capabilities. The shielded design minimizes electromagnetic interference, making it suitable for noise-sensitive applications. Ensure the operating temperature range aligns with the target environment requirements.

Fixed Inductors Part Context

This part belongs to the VLF series, which utilizes optimized magnetic materials to achieve high efficiency in voltage conversion. The series is engineered specifically for size-constrained mobile equipment and portable electronics requiring reliable power filtering.
