WP28020015

$35.59

Description：RF MOSFET GAN HEMT 28V DIE
Series：-

SKU:2790ec7e67ec Category: RF FETs, MOSFETs Brand: WAVEPIA.,Co.Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF MOSFET GAN HEMT 28V DIE
Series：-
Mfr：WAVEPIA.,Co.Ltd
Package：Box
Technology：GaN HEMT
Frequency：15GHz
Gain：10dB
Voltage - Test：28 V
Current Rating (Amps)：880mA
Noise Figure：-
Current - Test：300 mA
Power - Output：15W
Voltage - Rated：28 V
Grade：-
Qualification：-
Mounting Type：-
Package / Case：Die
Supplier Device Package：Die
Configuration：-

Download product information

WP28020015

Overview

The WP28020015 is a bare-die Gallium Nitride High Electron Mobility Transistor (GaN HEMT) manufactured by WAVEPIA Co., Ltd. It operates at a drain voltage of 28V with a breakdown voltage exceeding 100V. The device supports operation up to 20 GHz and delivers a typical saturated output power of 15W at 8.15 GHz, accompanied by a small signal gain of 10.0 dB. Key electrical parameters include a threshold voltage of -3.2V, a maximum drain-source current of 1050 mA/mm, and a peak transconductance of 340 mS/mm. At 8.15 GHz, the drain efficiency exceeds 40% with an intermodulation distortion below -30 dBc.
