049US2-1.8432F18HPJJK

Crystals Overview

The 049US2-1.8432F18HPJJK is a quartz crystal resonator manufactured by Suzhou Hangjing Elec&Tech Co.,Ltd. It operates at a fundamental frequency of 1.8432 MHz with a frequency tolerance of ±30ppm. The component features a load capacitance of 18pF and an equivalent series resistance (ESR) of 0 Ohms. It utilizes the HC-49 package style and employs gull-wing leads for surface mount installation.

Crystals Feature Summary

• Utilizes HC-49 package configuration
• Features gull-wing lead termination
• Designed for surface mount applications

Crystals Applications

• Frequency control in electronic circuits
• Quartz frequency controlling units
• Oscillator circuit integration

Crystals Procurement Notes

Verify the manufacturer part number 049US2-1.8432F18HPJJK against official Suzhou Hangjing documentation to confirm specifications. Ensure compatibility with 1.8432 MHz frequency requirements, 18pF load capacitance, and HC-49 gull-wing package constraints before procurement. Cross-reference datasheets for electrical parameters.

Crystals Selection Notes

Select this component when a 1.8432 MHz quartz crystal with ±30ppm stability is required. The HC-49 gull-wing package suits surface mount designs needing low ESR. Confirm that the 18pF load capacitance matches the oscillator circuit design. Validate that the manufacturer's frequency control capabilities meet project standards.

Crystals Part Context

Suzhou Hangjing Elec&Tech Co.,Ltd specializes in quartz frequency control components. This model belongs to their range of crystals designed for precise timing applications. The company focuses on research, development, and production of such electronic components.

Crystals Replacement Considerations

No public substitute part numbers are confirmed in the provided data. Verify direct replacements only through official manufacturer cross-reference lists or authorized distributor databases.
