1-794107-1

Headers, Male Pins Overview

The TE Connectivity 1-794107-1 is a right-angle header connector belonging to the MATE-N-LOK series. It features 22 positions arranged in a dual-row configuration with a 4.14 mm pitch. The component utilizes brass pins with gold plating and a nylon housing rated UL 94 V-0. Designed for through-hole PCB mounting, it supports a voltage rating of 600 V and a current rating of 9.5 A.

Headers, Male Pins Feature Summary

• Right-angle board-to-wire design for efficient space utilization
• Gold-plated brass contacts ensure reliable electrical performance
• Nylon housing provides structural integrity and flame resistance

Headers, Male Pins Applications

• General-purpose electrical connections
• Board-to-wire interconnects
• Industrial equipment wiring

Headers, Male Pins Procurement Notes

Verify the specific contact plating finish against project requirements, as similar part numbers in this series may utilize tin plating instead of gold. Confirm that the 4.14 mm pitch aligns with the mating cable assembly specifications. Ensure the through-hole mounting style matches the target printed circuit board layout constraints.

Headers, Male Pins Selection Notes

Select this model when a robust, high-current connection is required for general-purpose applications. The dual-row arrangement accommodates higher pin counts within a compact footprint. Consider the right-angle orientation to facilitate directional cable routing and reduce profile height on the assembly.

Headers, Male Pins Part Context

This component is part of the MATE-N-LOK family, known for its versatility in power and signal applications. The series offers various position counts and configurations to support diverse industrial needs. TE Connectivity manufactures these connectors to meet rigorous reliability standards for demanding environments.

Headers, Male Pins Replacement Considerations

The part number 794107-1 serves as a substitute option within the same series. Note that this alternative typically features tin-plated contacts rather than gold. Verify compatibility regarding contact material properties and environmental resistance before implementation.
