1-794108-1

Headers, Male Pins Overview

The 1-794108-1 is a dual-row pin header from the Mini-Universal MATE-N-LOK series by TE Connectivity AMP Connectors. It features 24 positions with a 4.14 mm pitch and right-angle through-hole termination for PCB mounting. The contacts are made of brass with gold plating, while the housing is white nylon rated UL 94 V-0. Rated at 600 V and 9.5 A, it serves as a plug interface in board-to-wire applications.

Headers, Male Pins Feature Summary

• Dual-row configuration providing 24 contact positions
• Right-angle design optimized for board-to-wire connections
• Gold-plated brass contacts ensuring reliable conductivity
• Nylon housing with UL 94 V-0 flammability rating

Headers, Male Pins Applications

• Board-to-wire interconnections
• Mini-Universal MATE-N-LOK system integration
• Industrial equipment signal routing
• Power distribution modules

Headers, Male Pins Procurement Notes

Verify the specific part number against official TE Connectivity documentation to confirm current availability status. Check for any product change notices or discontinuance alerts prior to procurement. Ensure compatibility with mating sockets within the Mini-Universal MATE-N-LOK family. Confirm environmental compliance requirements match project specifications.

Headers, Male Pins Selection Notes

Select this component for applications requiring high voltage isolation up to 600 V. The right-angle form factor aids in space-constrained PCB layouts. Gold plating offers superior corrosion resistance compared to tin variants. Verify that the 4.14 mm pitch aligns with existing mechanical constraints and mating connector specifications.

Headers, Male Pins Part Context

This header belongs to the Mini-Universal MATE-N-LOK series, designed for robust electrical connections. The series supports various circuit counts and termination styles. TE Connectivity AMP Connectors manufactures these components for industrial and commercial use. The dual-row layout maximizes density while maintaining safety clearances.

Headers, Male Pins Replacement Considerations

Consult official TE Connectivity substitution guides for verified alternatives. Cross-reference mating socket part numbers for compatibility. Ensure replacement parts maintain identical pitch, row count, and current ratings.
