1-87230-3

Headers, Male Pins Overview

The 1-87230-3 is a header connector from the AMPMODU Mod II series, manufactured by TE Connectivity AMP Connectors. It features a right-angle through-hole mounting style with a single row of three positions. The connector utilizes a 0.100-inch (2.54mm) pitch and employs solder termination for PCB attachment. Contact materials consist of phosphor bronze with gold plating to ensure reliable electrical performance.

Headers, Male Pins Feature Summary

• Right-angle design facilitates compact board-to-board or cable-to-board interconnections
• Gold-plated phosphor bronze contacts provide durable conductivity and corrosion resistance
• Through-hole solder termination ensures secure mechanical fixation on printed circuit boards

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Cable-to-board wiring assemblies
• General electronic equipment signal routing

Headers, Male Pins Procurement Notes

Verify component authenticity against official TE Connectivity documentation. Confirm that the part number matches the specific AMPMODU Mod II series designation. Ensure compatibility with mating connectors regarding pin count and pitch dimensions before integration into final assembly designs.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required for three-position circuits. Verify that the operating temperature range aligns with system requirements. Ensure the chosen housing accommodates the necessary contact types and that the soldering process supports the specified termination method.

Headers, Male Pins Part Context

This component belongs to the AMPMODU Mod II family, a widely used rectangular connector system known for its versatility in various industrial applications. The series offers multiple configurations including different pin counts, orientations, and insulation heights, providing engineers with standardized interconnect solutions.

Headers, Male Pins Replacement Considerations

Consult TE Connectivity official databases for current availability status. Identify direct cross-references within the same series if obsolescence occurs. Validate mechanical fit and electrical specifications before substituting with alternative manufacturers' products.
