22173112

Headers, Receptacles, Female Sockets Overview

Molex part number 22173112 is a manual hand crimp tool designed for processing contacts. It belongs to the 173112 series, which features a mini frame construction and an 8-step adjustment mechanism. The tool is engineered for use with D-Sub connectors and high-density contacts, providing precise crimping capabilities through its manual operation interface.

Headers, Receptacles, Female Sockets Feature Summary

• Manual hand crimp tool design
• Mini frame construction
• 8-step adjustment mechanism
• Compatible with D-Sub and high-density contacts

Headers, Receptacles, Female Sockets Applications

• Crimping D-Sub connector contacts
• Processing high-density electrical contacts
• Manual assembly of connector housings

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific contact size compatibility before ordering, as the 173112 series includes variants tailored for different terminal dimensions. Confirm that the required crimping range aligns with the tool's 8-step adjustment specifications to ensure proper termination quality and mechanical integrity.

Headers, Receptacles, Female Sockets Selection Notes

Select this tool when working with D-Sub or high-density contacts requiring manual precision. The 8-step adjustment allows for fine-tuning crimp force and depth. Ensure the tool variant matches the specific contact geometry needed for the target application to maintain consistent connection reliability.

Headers, Receptacles, Female Sockets Part Context

The 22173112 identifier corresponds to Molex's 173112 series of hand tools. This series is characterized by its compact mini frame and adjustable crimping settings. It serves as a specialized instrument for technicians performing manual termination tasks on complex connector systems.

Headers, Receptacles, Female Sockets Replacement Considerations

Public documentation does not list confirmed substitute part numbers for this specific component. Users should consult official Molex catalogs for compatible alternatives within the same series or functionally equivalent manual crimping tools.
