305-014-521-512

Edgeboard Connectors Overview

The EDAC Inc. 305-014-521-512 is a standard card edge connector designed for vertical panel mounting applications. It features a dual-row configuration with 14 positions and utilizes gold-plated copper alloy contacts to ensure reliable signal transmission. The component accommodates printed circuit boards with a nominal thickness of 1.57 mm (0.062 inches). Electrical specifications include a continuous current rating of 5 A and an insulation resistance of 5 GOhms, supporting operation within a temperature range of -40°C to +105°C.

Edgeboard Connectors Feature Summary

• Accepts between-contact and in-contact polarizing keys for secure board alignment
• Features a low profile thermoplastic insulator body for compact integration
• Utilizes solder pin termination for robust mechanical attachment

Edgeboard Connectors Applications

• Industrial control systems requiring high-density interconnects
• Automotive electronics modules
• Medical device instrumentation
• Communication equipment backplanes

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to confirm contact plating, row count, and termination style. Ensure that the selected variant matches the required PCB thickness and mounting orientation for your design. Cross-reference the manufacturer part number with authorized distributor catalogs to confirm availability and compliance with relevant environmental standards such as RoHS before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this connector when a dual-row, 14-position interface is required for vertical panel mounting. Confirm compatibility with the target PCB's nominal thickness of 1.57 mm and verify that the 3.96 mm contact spacing aligns with the board layout. Ensure the application environment falls within the specified operating temperature range and that the 5 A current rating meets the system's electrical load requirements.

Edgeboard Connectors Part Context

This component belongs to the EDAC 305 series of standard card edge connectors, which are engineered for demanding industrial and commercial environments. The series offers various position counts and row configurations to support diverse connectivity needs. These connectors are widely utilized in sectors requiring durable, high-reliability interfaces for electronic assemblies.

Edgeboard Connectors Replacement Considerations

Compatible substitutes within the EDAC 305 family include models with identical row counts and pitch but differing position numbers or termination styles. Verify that any alternative part maintains the same 3.96 mm contact spacing and 1.57 mm PCB thickness acceptance to ensure mechanical fit.
