305-014-556-501

Edgeboard Connectors Overview

The EDAC Inc. 305-014-556-501 is a standard card edge connector from the 305 series, designed for dual-row female connections with 14 positions. It features a 3.96 mm (0.156 inch) pitch and supports a maximum current rating of 5 A per contact. The connector utilizes gold-plated copper alloy contacts and a green thermoplastic insulator. It is engineered for panel mounting in a vertical orientation and employs solder pin termination. The unit accommodates a PCB thickness of 1.57 mm and operates within a temperature range of -40°C to +105°C.

Edgeboard Connectors Feature Summary

• Dual-row configuration providing 14 connection points with a 3.96 mm pitch
• Gold-plated copper alloy contacts ensuring reliable signal transmission
• Vertical panel mount design with solder pin termination for secure installation

Edgeboard Connectors Applications

• Industrial control systems requiring robust card edge interfaces
• Telecommunications equipment utilizing standard board thicknesses
• Test and measurement instrumentation needing high-reliability connectors

Edgeboard Connectors Procurement Notes

Verify that the specific part number matches the required 14-position dual-row configuration before procurement. Confirm compatibility with the target PCB stack-up, specifically the 1.57 mm thickness requirement. Ensure the application environment falls within the specified -40°C to +105°C operating temperature range. Check for any specific RoHS compliance documentation requirements relevant to your region's regulations.

Edgeboard Connectors Selection Notes

Select this component when a dual-row card edge connector with a 3.96 mm pitch is required. It is suitable for applications demanding a 5 A current rating and vertical panel mounting. Consider the green thermoplastic housing and gold plating for corrosion resistance. Ensure the design allows for solder pin termination without the need for mounting lugs.

Edgeboard Connectors Part Context

This component belongs to the EDAC 305 series, which specializes in standard card edge connectors. The series offers various position counts and mounting options while maintaining consistent electrical characteristics. The 305-014-556-501 variant specifically addresses needs for 14-position dual-row connectivity in compact electronic assemblies.

Edgeboard Connectors Replacement Considerations

Consult official EDAC documentation for direct cross-reference part numbers. Verify that any substitute maintains the 3.96 mm pitch, 14-position count, and dual-row configuration. Ensure mechanical dimensions and thermal ratings match the original specifications.
