305-016-500-512

$6.15

Description：CONN EDGE DUAL FMALE 16POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Bulk

SKU:c79e99d74265 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

305-016-500-512 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 16POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 305-016-500-512

Description：CONN EDGE DUAL FMALE 16POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：8
Number of Positions：16
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Panel Mount
Termination：Solder Eyelet(s)
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Semi Bellows
Color：Green
Flange Feature：Flush Mount, Side Opening, Unthreaded, 0.128" (3.25mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 305-016-500-512

305-016-500-512

Edgeboard Connectors Overview

The EDAC Inc. 305-016-500-512 is a standard card edge connector featuring 16 positions arranged in a dual row configuration. It utilizes a 3.96 mm (0.156 inch) contact pitch with a 3.56 mm (0.140 inch) row spacing. Designed for .062 inch (1.57 mm) nominal thickness printed circuit boards, this header employs gold-plated copper alloy contacts and a green thermoplastic insulator body. The unit supports a current rating of 5 A and offers vertical panel mount installation with solder lug termination.

Edgeboard Connectors Feature Summary

Dual row female contact configuration for high-density board connections
Gold-plated copper alloy contacts ensure reliable signal transmission
Low profile insulator body design accommodates space-constrained applications
Vertical panel mount style provides secure structural integration

Edgeboard Connectors Applications

Industrial control systems requiring robust card edge interfaces
Communication equipment utilizing standard PCB thicknesses
Automotive electronics demanding reliable vertical mounting solutions

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against official EDAC documentation to confirm exact termination type and plating specifications. Ensure compatibility with the target PCB thickness of 1.57 mm before procurement. Confirm that the vertical panel mount orientation aligns with the mechanical assembly requirements. Cross-reference the 16-position count with the schematic to prevent mismatched interface designs during component sourcing.

Edgeboard Connectors Selection Notes

Select this component when a dual-row card edge connector with a 3.96 mm pitch is required for .062 inch thick boards. The 5 A current rating suits moderate power distribution needs within the connector interface. Consider the vertical panel mount style if space constraints prohibit horizontal layouts. Verify that the solder lug termination method matches the available manufacturing processes for the final assembly line.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 series of standard card edge connectors. The series is characterized by its consistent 3.96 mm contact spacing across various position counts. The 305 series headers are engineered for durability and reliable performance in demanding electronic environments, offering a standardized solution for interconnecting circuit boards through edge-mounted interfaces.
