307-036-427-168

Edgeboard Connectors Overview

The EDAC Inc. 307-036-427-168 is a standard card edge connector receptacle featuring 36 positions with a 3.96 mm (0.156 inch) pitch. Designed for single-sided board insertion, it utilizes gold-plated copper alloy contacts and a green thermoplastic housing. The component supports a current rating of 5 A and operates within a temperature range of -40°C to +105°C. It employs a solder pin termination style and accommodates PCB thicknesses up to 1.57 mm.

Edgeboard Connectors Feature Summary

• Single-edge female contact configuration for non-specified card types
• Gold-plated copper alloy contacts ensure reliable signal transmission
• Thermoplastic polyester housing provides structural stability
• Solder pin termination facilitates secure panel or PCB mounting

Edgeboard Connectors Applications

• Industrial control system interconnects
• Telecommunications equipment backplanes
• Test and measurement instrument interfaces
• General-purpose electronic module connections

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to confirm contact plating and housing color specifications. Ensure compatibility with target PCB thickness limits before procurement. Confirm RoHS compliance status through manufacturer datasheets. Validate that the single-edge receptacle design matches the intended card edge geometry for proper mechanical engagement.

Edgeboard Connectors Selection Notes

Select this component when a 36-position interface with a 3.96 mm pitch is required. Consider the 5 A current rating and thermal operating range for environmental suitability. Evaluate the single-edge versus dual-edge requirement based on circuit layout. Verify that the solder pin termination method aligns with available assembly processes and panel mounting constraints.

Edgeboard Connectors Part Context

This part belongs to the EDAC 307 series of standard card edge connectors. The series offers various position counts and mounting configurations. Components in this family share common dimensional standards and material properties, ensuring interchangeability within design parameters while allowing customization through specific ordering suffixes for plating and orientation.

Edgeboard Connectors Replacement Considerations

Cross-reference with EDAC part numbers sharing the same 307 series designation and 36-position count. Verify identical pitch, termination type, and contact configuration before substitution. Ensure mechanical dimensions and electrical ratings match the original design requirements.
