345-009-524-678

$8.18

Description：CONN EDGE SINGLE FML 9POS 0.100
Series：345
Mfr：EDAC Inc.
Package：Box

SKU:748b3123e6da Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

345-009-524-678 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE SINGLE FML 9POS 0.100. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 345-009-524-678

Description：CONN EDGE SINGLE FML 9POS 0.100
Series：345
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Single Edge
Gender：Female
Number of Positions/Bay/Row：9
Number of Positions：9
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：1
Pitch：0.100" (2.54mm)
Read Out：Single
Features：Card Guides
Mounting Type：Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Green
Flange Feature：Top Mount Opening, Threaded Insert, 4-40
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 345-009-524-678

345-009-524-678

Edgeboard Connectors Overview

The EDAC Inc. 345-009-524-678 is a standard card edge connector socket featuring 9 positions in a single row configuration. It utilizes a 0.100-inch (2.54 mm) pitch and employs PC pin termination for through-hole mounting. The connector is designed with a vertical orientation and accepts board thicknesses of 1.57 mm. Contact surfaces are gold-plated copper alloy, providing reliable electrical performance within an operating temperature range of -40°C to 105°C.

Edgeboard Connectors Feature Summary

Vertical through-hole mounting style with PC pin termination
Gold-plated copper alloy contacts for signal integrity
Single-row female connector design for non-specified cards

Edgeboard Connectors Applications

General electronic circuit interconnections
Industrial control system modules
Consumer electronics assembly

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to ensure compatibility with required board thickness and contact plating specifications. Confirm that the single-row configuration aligns with the target PCB layout requirements before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a single-row, 9-position interface is required for vertical mounting applications. Ensure the target printed circuit board accommodates the specified 0.100-inch pitch and compatible hole dimensions for the PC pin termination style.

Edgeboard Connectors Part Context

This part belongs to the EDAC 345 series of standard card edge connectors. The series offers various position counts and row configurations, utilizing consistent 0.100-inch pitch spacing across the product line to maintain uniformity in mechanical design and installation procedures.

Edgeboard Connectors Replacement Considerations

Direct substitutes include other EDAC 345 series variants with matching 9-position single-row specifications. Cross-brand replacements require verification of identical pitch, terminal type, and mounting orientation parameters.
