435-90-220-00-160000

Headers, Male Pins Overview

The Mill-Max 435-90-220-00-160000 is a 20-position vertical header connector from the 435 Series. It features a 2.54mm (0.1 inch) centerline pitch and brass alloy contacts with gold plating. Designed for through-hole solder termination, this component provides a reliable interconnection solution for printed circuit boards.

Headers, Male Pins Feature Summary

• Vertical board-to-board or device connection architecture
• Gold-plated brass alloy contact surfaces for conductivity
• Through-hole solder termination method

Headers, Male Pins Applications

• Interconnecting multiple printed circuit boards
• Connecting peripheral devices to main logic boards
• High-density electronic assembly integration

Headers, Male Pins Procurement Notes

Verify the specific pin count and row configuration against the datasheet to ensure compatibility with the target PCB footprint. Confirm that the gold plating thickness meets the required durability standards for the intended mating cycles. Check RoHS compliance status if environmental regulations apply to the final product assembly.

Headers, Male Pins Selection Notes

Select this connector when a low-profile vertical header is required for 2.54mm pitch applications. The brass alloy construction offers cost-effectiveness compared to beryllium copper alternatives. Ensure the mounting hole dimensions align with the PCB design constraints for secure mechanical fixation during soldering.

Headers, Male Pins Part Context

This part belongs to the Mill-Max 435 Series of low-profile headers. The series is characterized by an above-board height of approximately 2.11mm, facilitating compact electronic designs. These components are engineered for high-reliability precision-machined interconnects in demanding environments.
