5977703602F

$1.03

Description：LED GREEN/RED CLEAR 1206 SMD
Series：597
Mfr：Dialight
Package：Strip

SKU:83c4720a9a85 Category: LED Indication - Discrete Brand: Dialight

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

5977703602F is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Dialight. Its product description is LED GREEN/RED CLEAR 1206 SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for 5977703602F

Description：LED GREEN/RED CLEAR 1206 SMD
Series：597
Mfr：Dialight
Package：Strip
Color：Green, Red
Configuration：Independent
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：45mcd Green, 55mcd Red
Lens Style：Rectangle with Flat Top
Lens Size：1.50mm x 1.60mm
Voltage - Forward (Vf) (Typ)：2V Green, 2V Red
Current - Test：20mA Green, 20mA Red
Viewing Angle：130°
Mounting Type：Surface Mount, Bottom Entry
Wavelength - Dominant：571nm Green, 631nm Red
Wavelength - Peak：574nm Green, 639nm Red
Features：-
Package / Case：1206 (3216 Metric)
Supplier Device Package：1206
Size / Dimension：3.20mm L x 1.60mm W
Height (Max)：1.10mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for 5977703602F

5977703602F

LED Indication - Discrete Overview

The Dialight 5977703602F is a surface-mount bi-color LED indicator in a 1206 (3216 metric) package. It features independent green and red emitters with a clear, colorless lens. The device operates at a forward current of 20mA for both colors, with typical forward voltages of 2V for green and 2V for red. Peak wavelengths are specified at 574nm for green and 639nm for red. The component has a maximum height of 1.10mm and provides luminous intensities of 45mcd for green and 55mcd for red.

LED Indication - Discrete Feature Summary

Dual-chip configuration enabling independent control of green and red light outputs within a single surface-mount package.

LED Indication - Discrete Applications

Board status indication

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix to confirm lens clarity and wavelength specifications against the official datasheet. Confirm moisture sensitivity level (MSL 3) handling requirements during assembly. Ensure the selected packaging format matches production line capabilities.

LED Indication - Discrete Selection Notes

Select this component when space-constrained designs require distinct green and red signaling from a single footprint. The 1206 package offers a balance between visibility and board density. Verify voltage compatibility with drive circuits given the 2V forward voltage characteristic.

LED Indication - Discrete Part Context

This part belongs to the Dialight 597 series of surface-mount LEDs. It is designed for high-reliability electronic applications requiring compact, multi-color visual feedback. The series supports various lens types and color combinations for diverse industrial and commercial uses.
