5988G10313F

$0.37

Description：LED RED CLEAR 1204 SMD 13" RL
Series：598
Mfr：Dialight
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:ea7e71dba1c5 Category: LED Indication - Discrete Brand: Dialight

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

5988G10313F is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Dialight. Its product description is LED RED CLEAR 1204 SMD 13" RL. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for 5988G10313F

Description：LED RED CLEAR 1204 SMD 13" RL
Series：598
Mfr：Dialight
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Red
Configuration：-
Lens Color：-
Lens Transparency：Clear
Millicandela Rating：-
Lens Style：Rectangle with Domed Top
Lens Size：2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ)：-
Current - Test：-
Viewing Angle：-
Mounting Type：Surface Mount
Wavelength - Dominant：635nm
Wavelength - Peak：-
Features：-
Package / Case：1204 (3210 Metric)
Supplier Device Package：1204
Size / Dimension：3.20mm L x 1.00mm W
Height (Max)：1.60mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for 5988G10313F

5988G10313F

LED Indication - Discrete Overview

The Dialight 5988G10313F is a red light-emitting diode designed for surface-mount technology applications. It features a clear lens with a rectangular shape and a domed top, housed in a 1204 (3210 metric) package measuring 3.20mm in length, 1.00mm in width, and a maximum height of 1.60mm. The component emits light at a primary wavelength of 635nm. It is classified as a discrete indicator LED within the 598 series and is currently active in production.

LED Indication - Discrete Feature Summary

Surface-mount installation capability for automated assembly processes
Clear lens construction providing a rectangular profile with a domed finish
Discrete indicator classification for visual status signaling

LED Indication - Discrete Applications

Visual status indication on electronic circuit boards
Panel-mounted indicator lights requiring low-profile components
Consumer electronics device status signaling

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix to ensure the correct packaging configuration matches your assembly requirements. Confirm that the moisture sensitivity level 5A rating aligns with your facility's floor life management protocols. Check RoHS3 compliance documentation if required by your supply chain standards. Ensure the 1204 package dimensions fit within your designated footprint constraints.

LED Indication - Discrete Selection Notes

Select this component when a red 635nm emission is required for a compact surface-mount application. The 1204 package offers a balance between visibility and board space efficiency. Consider the rectangular domed lens style for specific optical distribution needs. Verify thermal management requirements relative to the intended operating current and ambient conditions.

LED Indication - Discrete Part Context

This part belongs to the Dialight 598 series of single-color LEDs. The series provides various color and package options for general-purpose indication. The 5988G variant specifically denotes the red emission and 1204 package type. It is distinct from other series like the 515 Optopipe line which serves different optical guiding functions.
