7P-38.400MBP-T

Oscillators Overview

The 7P-38.400MBP-T is a standard clock oscillator manufactured by TXC Corporation, operating at a frequency of 38.4 MHz. It features a CMOS output format and supports a supply voltage range from 2.97 V to 3.63 V. The device exhibits a frequency stability of 0.28 ppm and utilizes a 15 pF load capacitance. Designed for surface mount applications, it measures 7 mm in length, 5 mm in width, and 1.3 mm in height. The component operates within a temperature range of -40°C to +85°C.

Oscillators Feature Summary

• Provides precise frequency stabilization with 0.28 ppm stability.
• Features CMOS output format for digital interface compatibility.
• Supports enable/disable functionality via control pin.

Oscillators Applications

• Precision timing circuits requiring low phase noise.
• Communication systems utilizing 38.4 MHz reference clocks.
• Embedded devices needing stable CMOS clock sources.

Oscillators Procurement Notes

Verify the specific ordering suffix to ensure the correct package type and tape/reel configuration match your assembly requirements. Confirm that the supply voltage range aligns with your system's power rails. Check for any recent lifecycle notifications or obsolescence warnings directly from the manufacturer before finalizing procurement plans.

Oscillators Selection Notes

Select this model when high frequency accuracy is critical for system synchronization. Ensure the PCB layout accommodates the 7x5 mm SMD footprint. Verify that the thermal environment stays within the specified -40°C to +85°C operational range to maintain the stated 0.28 ppm stability performance throughout the product's service life.

Oscillators Part Context

This component belongs to the 7P series of standard oscillators from TXC Corporation. It is designed as a direct replacement for general-purpose crystal oscillators in applications demanding higher stability than basic quartz crystals but without the complexity of TCXO units. The series offers various frequency options within the same physical package.

Oscillators Replacement Considerations

The 7N-38.400MBP-T is a documented substitute offering similar frequency and package dimensions but with different stability characteristics. Verify electrical compatibility regarding supply voltage and output drive strength before substitution.
