7P-40.000MBP-T

Oscillators Overview

The TXC Corporation 7P-40.000MBP-T is a temperature-compensated crystal oscillator (TCXO) operating at a frequency of 40 MHz. It utilizes CMOS output logic and functions within a supply voltage range of 2.7 V to 5.5 V, with specific configurations supporting 3.3 V enable/disable control. The component features a 10-SMD, no-lead package design. Frequency stability is specified at ±0.28 ppm across the industrial temperature range of -40°C to +85°C.

Oscillators Feature Summary

• Temperature compensation ensures high frequency stability of ±0.28 ppm across the operational temperature range.
• CMOS output interface provides digital signal compatibility for integrated circuit applications.
• Wide supply voltage operation supports flexibility from 2.7 V to 5.5 V.
• Integrated enable/disable functionality allows for power management control.

Oscillators Applications

• Telecommunications equipment requiring precise clock synchronization
• Wireless communication modules needing stable carrier frequencies
• Industrial control systems operating in varying environmental temperatures
• Consumer electronics utilizing high-frequency timing references

Oscillators Procurement Notes

Verify the specific pinout configuration against the official datasheet before integration, as the 10-SMD no-lead package requires precise footprint alignment. Confirm that the selected supply voltage aligns with the device's operational limits and that the enable/disable control signals are correctly interfaced with the host system logic levels to ensure proper functionality.

Oscillators Selection Notes

Select this component when application requirements demand superior frequency stability compared to standard oscillators, specifically within the ±0.28 ppm tolerance. Ensure the design accommodates the 10-SMD no-lead form factor and that the host circuitry supports the required CMOS output swing and supply voltage range between 2.7 V and 5.5 V.

Oscillators Part Context

This part belongs to the TXC 7P series of TCXOs, designed for applications requiring compact size and high performance. It serves as a precision timing source where environmental temperature fluctuations would otherwise degrade signal integrity. The series targets markets demanding reliable clock generation in space-constrained electronic assemblies.

Oscillators Replacement Considerations

Publicly confirmed substitute part numbers were not identified in the provided documentation. Verify compatibility with alternative TCXO models by matching frequency, stability, package dimensions, and electrical specifications.
