7W-35.328MBB-T

Oscillators Overview

The TXC Corporation 7W-35.328MBB-T is a standard crystal oscillator (XO) operating at a nominal frequency of 35.328 MHz. It utilizes CMOS output logic and functions with a supply voltage range of 1.8V to 5V, typically centered around 3.3V. The device features a frequency stability of ±100 ppm and operates within a commercial temperature range of -10°C to +70°C. It is housed in a compact 4-pin Surface Mount Device (SMD) package measuring 7mm x 5mm, designed for tape and reel packaging.

Oscillators Feature Summary

• CMOS output compatibility for digital circuit integration
• Wide supply voltage operation from 1.8V to 5V
• Compact 7mm x 5mm SMD footprint

Oscillators Applications

• Standard clock signal generation for microprocessors
• Timing reference for communication interfaces
• General purpose timing in consumer electronics

Oscillators Procurement Notes

Verify the specific ordering suffix against manufacturer documentation to confirm exact electrical tolerances and packaging specifications. Ensure the requested part matches the required frequency stability and voltage parameters for the target application. Cross-reference the datasheet for pinout configurations and recommended soldering profiles to guarantee assembly reliability.

Oscillators Selection Notes

Select this component when a 35.328 MHz timing source with CMOS outputs is required. Consider the ±100 ppm stability requirement and the -10°C to +70°C operating range. The wide voltage input allows flexibility in power supply design. Verify that the 7mm x 5mm package dimensions fit the available PCB space constraints.

Oscillators Part Context

This model belongs to the 7W series of standard crystal oscillators from TXC Corporation. These components are designed as direct replacements for discrete crystal resonators, offering integrated stability and ease of use. The series supports various frequencies and packages, providing a standardized solution for timing applications across different electronic product lines.

Oscillators Replacement Considerations

Compatible substitutes include other 35.328 MHz CMOS oscillators in similar SMD packages. Verify equivalent frequency stability, voltage ranges, and load capacitance requirements before substitution. Check for pin-to-pin compatibility and thermal performance alignment.
