801-87-006-30-480101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-87-006-30-480101 is a rectangular connector header from the 801 series, featuring six female socket contacts. It utilizes a 2.54 mm (0.100 inch) pitch and is designed for surface mount installation with right-angle orientation. The unit operates within a temperature range of -55°C to +125°C and carries UL94 V-0 flammability ratings. Contacts are gold-plated copper alloy, ensuring reliable signal transmission in board-to-board applications.

Headers, Receptacles, Female Sockets Feature Summary

• Female socket contact configuration accepts mating pins for secure interconnection
• Surface mount right-angle design facilitates compact PCB layout integration
• Gold-plated contacts provide corrosion resistance and stable electrical performance

Headers, Receptacles, Female Sockets Applications

• Board-to-board interconnections requiring right-angle routing
• Electronic assemblies needing reliable signal transmission in compact spaces
• Industrial control modules utilizing surface mount technology

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific ordering suffix matches the required contact plating and termination style. Confirm surface mount compatibility with your assembly process. Ensure the right-angle orientation aligns with your PCB footprint requirements before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, right-angle female socket connection is required for surface mounting. The 2.54 mm pitch ensures compatibility with standard pin headers. Consider the gold plating for environments where corrosion resistance is critical compared to tin alternatives.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Preci-Dip 801 series, which specializes in high-reliability rectangular connectors. The series offers various configurations including through-hole and surface mount options. The 801 series is widely used in industrial and commercial electronics for robust interconnect solutions.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes include other 6-position surface mount female sockets with 2.54 mm pitch and right-angle orientation. Verify mechanical dimensions and contact material specifications to ensure functional equivalence.
