807-018-558-201

Edgeboard Connectors Overview

The EDAC 807-018-558-201 is a standard card edge receptacle from the 807 High Temperature Series. It features 18 positions with a 3.96 mm (0.156 inch) contact spacing and 5.08 mm row spacing. Designed for double-row configurations, it accepts printed circuit boards with a nominal thickness of 1.57 mm (0.062 inch). The connector utilizes gold-plated copper alloy contacts and a Diallyl Phthalate (DAP) insulator housing. It supports a current rating of 5 A and operates within a temperature range of -40°C to +125°C.

Edgeboard Connectors Feature Summary

• High-temperature resistant construction using Diallyl Phthalate (DAP) materials
• Gold-plated copper alloy contacts for reliable signal transmission
• Low-profile insulator body design for space-constrained applications

Edgeboard Connectors Applications

• High-temperature electronic assemblies
• Industrial control systems requiring thermal stability
• Motherboard or daughterboard interconnects

Edgeboard Connectors Procurement Notes

Verify the specific suffix code against official EDAC documentation to confirm exact termination style and orientation. Ensure compatibility with the target PCB thickness of 1.57 mm. Confirm that the operating environment remains within the specified -40°C to +125°C range to maintain material integrity and electrical performance standards.

Edgeboard Connectors Selection Notes

Select this component when high-temperature performance is critical, as indicated by the 807 series designation. The 18-position count suits moderate-density interconnect needs. Verify that the right-angle mounting style aligns with the mechanical layout requirements of the host chassis and that the through-hole termination method matches the fabrication capabilities of the assembly line.

Edgeboard Connectors Part Context

This part belongs to the EDAC 807 series, which specializes in high-temperature card edge connectors. Unlike the standard 307 series, the 807 series employs DAP insulation to withstand elevated thermal conditions. This specific model represents a double-row receptacle configuration, distinguishing it from single-row headers or lower-count variants within the same product family.

Edgeboard Connectors Replacement Considerations

Cross-reference with other EDAC 807 series parts sharing the 18-position count and 3.96 mm pitch. Verify that alternative suffixes match the required termination type and mounting angle. Ensure any substitute maintains the DAP housing material to preserve the high-temperature operational capability defined by the series specifications.
