833-008-559-602

$30.51

Description：CONN EDGE SGL FMALE 8POS 0.156
Series：833
Mfr：EDAC Inc.
Package：Box

SKU:de28357c842d Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

833-008-559-602 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE SGL FMALE 8POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 833-008-559-602

Description：CONN EDGE SGL FMALE 8POS 0.156
Series：833
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Single Edge
Gender：Female
Number of Positions/Bay/Row：8
Number of Positions：8
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：1
Pitch：0.156" (3.96mm)
Read Out：Single
Features：-
Mounting Type：Through Hole, Right Angle
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Green
Flange Feature：Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia
Operating Temperature：-40°C ~ 125°C

Edgeboard Connectors datasheet and documents for 833-008-559-602

833-008-559-602

Edgeboard Connectors Overview

The EDAC Inc. 833-008-559-602 is a standard card edge connector from the 833 series, designed for single-edge board applications. It features an 8-position configuration with a 3.96 mm (0.156 inch) pitch. The connector supports a maximum PCB thickness of 1.57 mm and utilizes gold-plated copper alloy contacts rated for 3 A current. It employs a solder pin termination type and is constructed with a diallyl phthalate (DAP) housing.

Edgeboard Connectors Feature Summary

Gold-plated contacts ensure reliable signal transmission and corrosion resistance
Diallyl phthalate housing provides durable insulation properties
Solder pin termination facilitates secure panel mounting

Edgeboard Connectors Applications

Single-edge card edge interconnections
Panel-mounted electronic assemblies
Standard circuit board interfaces

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix to confirm the exact contact plating, orientation, and termination style required for your design. Confirm that the 3.96 mm pitch and 1.57 mm board thickness compatibility align with your PCB specifications. Ensure the 3 A current rating meets the electrical requirements of the application. Check manufacturer documentation for RoHS compliance details before finalizing procurement.

Edgeboard Connectors Selection Notes

Select this component when a vertical or right-angle single-row card edge connector is needed with a 3.96 mm pitch. The 8-position count suits low-pin-count interface requirements. Verify that the DAP material and gold plating meet environmental and conductivity standards. Ensure the solder pin termination method matches the assembly process capabilities.

Edgeboard Connectors Part Context

This part belongs to the EDAC 833 series of standard card edge connectors. The series offers various position counts and orientations to accommodate different board edge configurations. The 833 series is characterized by its robust construction and standardized dimensions, making it suitable for general-purpose industrial and commercial electronic interconnects requiring reliable single-edge connections.
