850-10-024-30-001000

Headers, Male Pins Overview

The Mill-Max 850-10-024-30-001000 is a surface mount pin header featuring 24 positions arranged in a single row. It utilizes a 0.050 inch (1.27mm) pitch spacing for compact circuit board integration. The connector employs gold-plated contacts to ensure reliable signal transmission and low contact resistance. Designed for high-reliability applications, it supports standard surface mount assembly processes while maintaining mechanical stability through precision-machined components.

Headers, Male Pins Feature Summary

• Precision-machined interconnect design for high reliability
• Gold-plated contact surfaces for corrosion resistance
• Surface mount termination for automated assembly

Headers, Male Pins Applications

• High-density electronic assemblies
• Precision instrumentation interfaces
• Compact consumer electronics modules

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Mill-Max documentation to confirm exact plating thickness and material composition. Ensure surface mount footprint compatibility with existing PCB designs before procurement. Cross-reference the manufacturer part number with authorized distributor catalogs to confirm current production status and availability constraints.

Headers, Male Pins Selection Notes

Select this component when space-constrained layouts require a single-row header with 1.27mm pitch. Evaluate thermal management requirements during soldering processes due to surface mount construction. Confirm that the 24-position count aligns precisely with interface requirements to avoid unused pins or insufficient connections.

Headers, Male Pins Part Context

This component belongs to the Mill-Max 850 series of standard pin headers. The series is characterized by precision-machined contacts and robust insulation materials. It serves as a critical interconnect solution within broader electronic systems requiring dependable electrical pathways.

Headers, Male Pins Replacement Considerations

Consult official Mill-Max substitution guides for compatible alternatives. Verify pin count, pitch, and mounting style match exactly before considering cross-brand replacements.
