Headers, Male Pins Overview

The Preci-Dip 894-70-075-10-004101 is a vertical header connector featuring 75 positions with a 2.54mm (0.100 inch) pitch. Designed for through-hole mounting, this single-row component utilizes gold-plated contacts to ensure reliable signal transmission in board-to-board applications. The unit operates within a temperature range of -55°C to 125°C and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Vertical pin configuration facilitates direct PCB insertion
• Gold contact plating provides corrosion resistance
• Single-row layout supports compact circuit designs

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Industrial control module interfaces
• General electronic equipment signal routing

Headers, Male Pins Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm current availability and lead times. Ensure compatibility with mating sockets regarding pitch and row count. Check for RoHS compliance requirements if applicable to your project specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a high-density vertical header is required for single-row connections. Consider the 2.54mm pitch standard for broad mating compatibility. Evaluate the gold plating thickness if long-term reliability in harsh environments is critical compared to tin alternatives.

Headers, Male Pins Part Context

This model belongs to the Preci-Dip 894 series of rectangular connectors. It serves as a male header variant designed for surface or through-hole integration. The series offers various position counts to accommodate different circuit density requirements while maintaining consistent mechanical dimensions.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 75-position, 2.54mm pitch vertical headers from manufacturers such as Samtec or Molex. Verify that replacement parts match the exact height, pin configuration, and termination style to ensure proper fit.
