8Z-40.000MAAE-T

Crystals Overview

The TXC Corporation 8Z-40.000MAAE-T is a surface-mount MHz crystal operating at 40.0000MHz with ±30ppm frequency tolerance and stability. It features a 12pF load capacitance and 60 Ohms impedance in a 4-SMD, no-lead package. The component supports an operating temperature range of -20°C to +70°C.

Crystals Feature Summary

• High precision frequency generation
• High frequency stability
• Surface-mount design

Crystals Applications

• Precise frequency generation circuits
• Electronic timing applications
• Communication systems requiring stable clock signals

Crystals Procurement Notes

Verify the specific manufacturer datasheet for the 8Z-40.000MAAE-T to confirm exact electrical parameters and mechanical dimensions. Ensure compatibility with your PCB footprint and thermal requirements before finalizing procurement decisions.

Crystals Selection Notes

Select this component when a 40MHz crystal with ±30ppm stability is required. Consider the 12pF load capacitance and 60 Ohms impedance for circuit matching. Verify the -20°C to +70°C temperature range meets application needs.

Crystals Part Context

This part belongs to the 8Z series of high-precision crystals from TXC Corporation. It is designed for applications demanding reliable frequency control in compact electronic devices, offering stability within tight tolerances.

Crystals Replacement Considerations

Consult official TXC documentation for direct substitutes. Cross-reference load capacitance, frequency tolerance, and package dimensions when evaluating alternative components.
