929705-06-16-I

Headers, Male Pins Overview

The 3M 929705-06-16-I is a board-to-board connector from the 929 series, designed for through-hole PCB mounting. It features a single row of 16 terminals with a 2.54 mm pitch and right-angle orientation. The contact surface material is gold-plated nickel, while the rear contact surface utilizes matte tin. Constructed with a fiberglass-reinforced polyester (PCT) insulator, this component supports a process temperature rating of 260 °C per J-STD-020C standards. Its low-profile design facilitates efficient wave soldering production via welding pillars.

Headers, Male Pins Feature Summary

• Right-angle configuration for compact vertical board stacking
• Gold-plated contacts ensure reliable signal transmission
• Welding pillars facilitate stable wave soldering processes
• Low-height structure allows close proximity between stacked boards

Headers, Male Pins Applications

• Board-to-board interconnections in industrial automation systems
• Data center hardware assembly requiring high-density connections
• Electronic equipment utilizing vertical PCB stacking architectures

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official datasheet to confirm terminal plating and insulation material specifications. Ensure compatibility with existing PCB footprint dimensions and wave soldering thermal profiles. Cross-reference technical sheet TS-0815 for precise mechanical tolerances and chemical compliance information before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this model when a right-angle, single-row connector is required for board-to-board applications. The 2.54 mm pitch suits standard spacing requirements, while the gold-plated contacts offer superior conductivity. Consider the low-profile design for space-constrained environments where vertical clearance is limited. Verify that the PCT insulation meets the necessary thermal resistance for the intended manufacturing process.

Headers, Male Pins Part Context

This component belongs to the 3M 929 series pin strip connectors, which are engineered for robust electronic interconnect solutions. The series offers various configurations including straight and right-angle options with different terminal counts. These connectors support both prototyping and production environments, providing flexibility for diverse electronic design needs across multiple industries.

Headers, Male Pins Replacement Considerations

Consult the official 3M replacement guide or technical documentation for verified substitute part numbers. Direct replacements must match the 2.54 mm pitch, 16-terminal count, right-angle orientation, and through-hole mounting style. Ensure any alternative maintains identical electrical ratings and mechanical dimensions to guarantee seamless integration.
