A-WBP-C001DG-A0SR03

$5.58

Description：WIRE-TO-BOARD, WAFER, 1.27MM, 10
Series：A-WBP
Mfr：Assmann WSW Components
Package：Tape & Reel (TR)

SKU:6c3d8a410dcb Category: Headers, Male Pins Brand: Assmann WSW Components

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

A-WBP-C001DG-A0SR03 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Assmann WSW Components. Its product description is WIRE-TO-BOARD, WAFER, 1.27MM, 10. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for A-WBP-C001DG-A0SR03

Description：WIRE-TO-BOARD, WAFER, 1.27MM, 10
Series：A-WBP
Mfr：Assmann WSW Components
Package：Tape & Reel (TR)
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.050" (1.27mm)
Number of Positions：100
Number of Rows：2
Row Spacing - Mating：0.050" (1.27mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.390" (9.91mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Liquid Crystal Polymer (LCP)
Features：Pick and Place, Solder Retention
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：1A
Voltage Rating：-

Headers, Male Pins datasheet and documents for A-WBP-C001DG-A0SR03

A-WBP-C001DG-A0SR03

Headers, Male Pins Overview

The A-WBP-C001DG-A0SR03 is a surface mount connector header manufactured by Assmann WSW Components. It features 100 positions with a 0.050-inch (1.27mm) pitch. The component utilizes a push-pull fastening mechanism and square contact shapes. Termination is achieved via soldering, ensuring secure board attachment. Insulation height is specified at 0.390 inches (9.91mm). This part is designed for high-density electronic interconnections requiring reliable surface mounting.

Headers, Male Pins Feature Summary

Surface mount construction for automated assembly integration
Push-pull fastening type for secure mating retention
Square contact shape design for precise alignment

Headers, Male Pins Applications

High-density circuit board interconnections
Server and storage backplane assemblies
Industrial control system modules

Headers, Male Pins Procurement Notes

Verify the exact pin count and pitch against the schematic before procurement. Confirm that the surface mount footprint matches the PCB layout dimensions precisely. Ensure the push-pull latching mechanism is compatible with the enclosure design constraints. Check for any specific RoHS compliance requirements if operating in regulated environments. Validate insulation height clearance against adjacent components on the board.

Headers, Male Pins Selection Notes

Select this component when a high-pin-count header is required for surface mount applications. The 1.27mm pitch offers a balance between density and manufacturability. The push-pull feature provides superior retention compared to standard friction-fit headers. Consider the 9.91mm insulation height for vertical spacing requirements. Ensure the square contact geometry aligns with the mating connector specifications.

Headers, Male Pins Part Context

This part belongs to the A-WBP series of connector headers from Assmann WSW Components. The manufacturer specializes in IC sockets and IDC connectors for flat cable applications. This specific model represents a high-density solution within their surface mount portfolio, targeting applications requiring robust mechanical retention and reliable electrical performance.
