A-WBP-O002EG-02TB01

Headers, Male Pins Overview

The A-WBP-O002EG-02TB01 is a connector header designed for through-hole mounting. It features two positions with a pitch of 0.118 inches (3.00 mm). The component is manufactured by Assmann WSW Components, a system supplier in the connectivity sector. This specific part number identifies a wafer header configuration suitable for PCB-to-cable connections.

Headers, Male Pins Feature Summary

• Through-hole mounting style for secure PCB attachment
• Two-position layout for signal or power transmission
• 3.00 mm pitch spacing between contacts

Headers, Male Pins Applications

• PCB-to-cable interconnections
• Wire-to-board assemblies
• General electronic device connectivity

Headers, Male Pins Procurement Notes

Verify the exact pin count and pitch against design requirements before ordering. Confirm that the through-hole footprint matches the PCB layout specifications. Ensure compatibility with mating connectors from the same product family. Check RoHS compliance status if required by project regulations. Validate mechanical dimensions to prevent assembly conflicts.

Headers, Male Pins Selection Notes

Choose this component when a low-profile, two-position connection is needed. The 3.00 mm pitch offers a balance between density and ease of handling. Through-hole technology provides robust mechanical stability compared to surface mount alternatives. Consider the overall height and contact length for enclosure clearance.

Headers, Male Pins Part Context

This part belongs to the A-WBP series of wire-to-board wafer headers from Assmann WSW. The series includes various position counts and pitch options. Similar parts like A-WBP-S002EG-02TB01 differ in pitch dimensions. The O suffix typically denotes specific housing characteristics within the product line.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other 2-position, 3.00 mm pitch headers from different manufacturers. Ensure mechanical compatibility and electrical ratings match. Verify that the mating connector interface remains unchanged. Cross-reference with Assmann WSW's updated catalog for potential newer revisions.
