Product Detailed Parameters
- Description：LED BLUE CLEAR SMD
- Series：-
- Mfr：Kingbright
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：Blue
- Configuration：Standard
- Lens Color：Colorless
- Lens Transparency：Clear
- Millicandela Rating：1300mcd
- Lens Style：Oval with Flat Top
- Lens Size：1.65mm x 1.15mm
- Voltage - Forward (Vf) (Typ)：3.3V
- Current - Test：20mA
- Viewing Angle：120°
- Mounting Type：Surface Mount
- Wavelength - Dominant：-
- Wavelength - Peak：-
- Features：-
- Package / Case：2-SMD, J-Lead
- Supplier Device Package：SMD
- Size / Dimension：2.00mm L x 1.40mm W
- Height (Max)：1.40mm
- Grade：-
- Qualification：-
Download product information
Overview
The AA2214VRBXS/A-TR-AMT is a single-color surface-mount LED manufactured by Kingbright, emitting ice blue light. It utilizes InGaN material and features a PLCC2 package with J-leads. The component has dimensions of 2.2 mm x 1.4 mm x 0.19 mm (X, Y, Height). Key electrical parameters include a forward voltage of 3.3 V at 20 mA and a power rating of 120 mW. The lens is yellow fluorescent with water clarity, providing a viewing angle of 120 degrees. It operates within a temperature range of -40°C to +85°C or +100°C depending on specific ratings.
Feature Summary
- Emits ice blue light using InGaN semiconductor technology
- Features a compact PLCC2 SMD package with J-leads for reliable mounting
- Includes a yellow fluorescent lens with water clear transparency
Applications
- LED indication circuits
- Electronic status indicators
- Consumer electronics displays
Procurement Notes
Verify the exact maximum operating temperature rating (+85°C vs +100°C) against the official Kingbright datasheet, as sources vary. Confirm moisture sensitivity handling requirements during storage and reflow soldering processes. Ensure the specific suffix /A-TR-AMT matches the required reel packaging configuration for automated assembly lines.
Selection Notes
Select this component when an ice blue indicator is required in a low-profile SMD design. The 3.3V forward voltage suits standard logic-level driving interfaces. The 120-degree viewing angle provides wide visibility. Consider the J-lead package style for mechanical stability compared to standard gull-wing leads.
Part Context
This part belongs to the Kingbright AA2214 series of single-color LEDs. It shares the physical footprint with other variants in the series but differs in emission color and lens treatment. The AA2214 series is designed for general-purpose indication applications requiring small form factors.
Replacement Considerations
Publicly confirmed direct substitute part numbers are not available in the provided documentation. Cross-reference with other Kingbright AA2214 series variants if different colors are acceptable, ensuring electrical parameters match.
